GIGABYTE 9 Series Black Edition Motherboards

Model name

Z97X-Gaming G1 WIFI-BK

Z97X-UD5H-BK

Z97X-UD3H-BK

CPU

4th & 5th Gen Intel® Core™ processors

Gniazdo procesora

LGA 1150

Chipset

Intel Z97 Chipset

Złącza graficzne

2*PCI-E 3.0 x16+2*PCI-E 3.0 x8

1*PCI-E 3.0 x16+
1*PCI-E 3.0 x8+1*PCI-E x4

Rodzaj pamięci

obsługa dwukanałowej pamięci DDR3

DIMM

4*DDR3

Expansion Slots

3*PCI-Ex1

2*PCI-E x1+2 PCI

3*PCI-E x1+1*PCI

SATA

10*SATA3, SATA EXPRESS

8 SATA3,M.2,SATA EXPRESS

6 SATA3,M.2,SATA EXPRESS

SATA RAID

RAID 0,1,5,10

USB

8*USB 3.0+8*USB 2.0

8*USB 3.0+6*USB 2.0

6*USB 3.0+8*USB 2.0

Audio

Creative Sound Core 3D

ALC1150 115dB HD audio

LAN

Dual GbE LAN(Killer+Intel)

Intel GbE LAN

Wyjścia Video

HDMI, DVI-I, DisplayPort

HDMI, DVI-D, D-SUB

Funkcje i oprogramowanie

Black edition,Water block thermal design,wsparcie dla 4 kart graficznych, Digital CPU Power design,Niezwykle trwałe czarne kondensatory polimerowe,High End Audio Caps,AMP-UP Audio,OP-AMP Upgradable, Gold Plated audio ports,Dual DAC-UP USB ports, Creative SBX Pro Studio™, WIFI+Bluetooth 4.0

Black edition, 2-way SLI / 3-way CrossFire Graphics support, IR Digital CPU Power design, Niezwykle trwałe czarne kondensatory polimerowe, 15µ Gold Plated CPU Socket, podwójna ilość miedzi w PCB, Dual BIOS with LED Indicators, zestaw przycisków, OC-PEG, Debug Display, Audio Noise Guard

Black edition, 2-way SLI / 3-way CrossFire Graphics support, Niezwykle trwałe czarne kondensatory polimerowe,
15µ Gold Plated CPU Socket, podwójna ilość miedzi w PCB, Dual BIOS, Audio Noise Guard, CFOS

Rozmiar (mm)

ATX (305X244)

ATX (305x225)

G1™ Wydajność	G1™ Audio
• Extreme Gaming 4-Way Graphics Support • Precise Digital CPU Power Design • SATA Express Support for up to 10 Gb/s Data Transfer • Long lifespan Durable Black Solid caps • GIGABYTE App Center Including EasyTune™ and Cloud Station™ Utilities • Onboard OC Quick Buttons	• Technologia GIGABYTE AMP-UP Audio - Creative Sound Core3D™ with Gold Plated Shielding - Swapable OP-AMP Technology with Gain Boost - Dedicated Audio Hardware Zone - Audio Noise Guard with Trace Path Lighting - Nichicon High-End Audio Capacitors • Gold Plated Audio Ports • Dual DAC-UP USB ports

G1™ Networking	G1™ Looks
• Killer E2200 Gaming Networking Platform / Intel GbE LAN • Bluetooth 4.0 + 867 Mbps 11AC Dual Band WIFI Card	• Locked and Loaded Extreme Water Block Thermal Design

Wzmacniacz słuchawkowy Swapable OP-AMP Technology with Gain Boost

Audio Noise Guard with Trace Path Lighting

High End Audio Capacitors

Quad Core Creative Sound Core3D with Custom Gold Plated Shielding

Killer E2200 Game Networking

Wsparcie dla 4 kart graficznych SLI™ / CrossFire™

GIGABYTE Patented DualBIOS™ Ze wskaźnikiem LED

Single BIOS Mode / DualBIOS™

	Killer E2200 Gaming Networking Platform / Intel GbE LAN

	Water Block Thermal Design with G1/4 Threaded Fittings	Trwałe kondensatory polimerowe
		8-pin CPU Power Connector
		15µ Gold Plated LGA 1150 CPU Socket

	IR Digital CPU Power design

	Dual Channel DDR3 Memory Slots

	zestaw przycisków Onboard Power, Reset, Clear CMOS Buttons, Voltage Read Points


	Debug Display
	USB 3.0

OC-PEG Extra Power Connector for Enhanced PCIe Stability

10 SATA 3 Connectors (Up to 6Gb/s)

SATA Express Connector (Up to 10Gb/s)

Front USB 3.0 Access Control Panel

7 x złącz Fan

	DAC-UP USB 2.0	Gold Plated DVI-I	USB 3.0	Dual GbE LAN (Intel^® + Killer)		Gold Plated Audio Jacks

PS/2 port

Gold Plated DisplayPort

Gold Plated HDMI

USB 3.0

Cyfrowe wyjście audio Audio

wyjście słuchawkowe OP-AMP Audio

*4K display support is dependent on CPU

Only 8 SATA3 connectors are available when SATA EXPRESS is enabled.

Wydajność	Durable
• Precise digital CPU power design • SATA Express Support for up to 10 Gb/s Data Transfer • M.2 Connector for SSDs Drives with up to 10 Gb/s Data Transfer • Killer E2200 Gaming Networking Platform / Intel GbE LAN • Realtek ALC1150 115dB SNR HD Audio with Built-in Rear Audio Amplifier • GIGABYTE App Center Including EasyTune™ and Cloud Station™ Utilities	• 2x Copper PCB Design (2 oz Copper PCB) • Long Lifespan Durable Black™ Solid Caps • Durable Gold Plated CPU Socket

Safe	Cool
• Patented DualBIOS™ (UEFI) Design • ESD Protection for USB and LAN • Power Failure Protection with Anti-Surge IC • Humidity Protection with Glass Fabric PCB	• All New Heat Sink Design • Highly efficient MOSFET design

Durable Black™ Solid Capacitors

Audio Noise Guard

Killer E2200 Gaming Networking

ALC1150 115dB HD audio

2-Way SLI™/ 3-Way CrossFire™
Multi-Graphics Support

M.2 Onboard Connector*
(Up to 10Gb/s)

GIGABYTE Patented DualBIOS™
Ze wskaźnikiem LED

OC-PEG Extra Power Connector for Enhanced PCIe Stability

	All New Heat Sink Design

	8-pin CPU Power Connector

	15µ Gold Plated LGA1150 CPU Socket

	IR Digital CPU Power design


			Dual Channel DDR3 Memory Slots

			zestaw przycisków Onboard Power, Reset, Clear CMOS Buttons, Voltage Read Points

		USB 3.0	Single BIOS Mode Switch DualBIOS™ DIP Switches

	Debug Display

	8 SATA 3 Connectors (Up to 6Gb/s)

SATA Express Connector (Up to 10Gb/s)*

6 Fan Connectors

SATA Express

*SATA Express connector & M.2 slot can only be enabled one at a time

	USB 2.0	D-SUB	USB 3.0	Dual GbE LAN (Intel^® + Killer)		8-ch HD Audio

PS/2 port

DVI-D

HDMI

USB 3.0

Cyfrowe wyjście audio Audio

*4K display support is dependent on CPU

Only 6 SATA3 connectors are available when SATA EXPRESS is enabled.

Wydajność	Durable
• SATA Express Support for up to 10 Gb/s Data Transfer • M.2 Connector for SSDs Drives with up to 10 Gb/s Data Transfer • Intel® GbE LAN with CFOS Internet Accelerator Software • Realtek ALC1150 115dB SNR HD Audio with Built-in Rear Audio Amplifier • GIGABYTE App Center Including EasyTune™ and Cloud Station™ Utilities	• 2x Copper PCB Design (2 oz Copper PCB) • Long Lifespan Durable Black™ Solid Caps • Durable Gold Plated CPU Socket

Safe	Cool
• Patented DualBIOS™ (UEFI) Design • ESD Protection for USB and LAN • Power Failure Protection with Anti-Surge IC • Humidity Protection with New Glass Fabric PCB	• All New Heat Sink Design! • Highly efficient MOSFET design

Durable Black™ Solid Capacitors

Audio Noise Guard

2-Way SLI™/ 3-Way CrossFire™
Multi-Graphics Support

115 dB HD Audio

M.2 Onboard Connector*
(Up to 10Gb/s)

GIGABYTE Patented DualBIOS™
(UEFI) Design

SATA Express Connector*
(Up to 10Gb/s)

	8-pin CPU Power Connector

	15µ Gold Plated LGA 1150 CPU Socket

	All New Heat Sink Design

	Dual Channel DDR3 Memory Slots

	6 SATA 3 Connectors (Up to 6Gb/s)

	Front USB 3.0

5 Fan Connectors

SATA Express

*SATA Express connector & M.2 slot can only be enabled one at a time

	Mouse Port	D-SUB	USB 3.0		Intel^® GbE LAN	8-ch HD Audio

Keyboard Port

DVI-D

HDMI

USB 2.0

USB 3.0

Cyfrowe wyjście audio Audio

*4K display support is dependent on CPU

Only 4 SATA3 connectors are available when SATA EXPRESS is enabled.

• Photos are for reference only. Motherboard specifications may vary by model.
• Specyfikacja oraz zdjęcia modeli mogą zostać zmienione bez wcześniejszego powiadomienia.
• Motherboard models may vary based on local distribution.
• Memory support is dependent on memory module compatibility and system OS.
• Please refer to GIGABYTE website for CPU support information.
• Wszystkie logotypy i znaki firmowe są własnością prawną firm i nie mogą być użyte bez ich zgody. Powyższa specyfikacja nie stanowi wiążącej oferty handlowej.
